HYDRAULIC CUTTING SHEARS
The range of EDILGRAPPA Hydraulic Cutting Shears is designed for industrial demolition and steel structure cutting applications. Their high cutting force ensures precision, efficiency, and outstanding performance across a wide range of demanding jobs.
The F200C Hydraulic Cutting Shear is designed to efficiently and accurately cut cables, pipes, steel sections, and beams.
The F250C Hydraulic Cutting Shear is engineered for more demanding steel cutting and metal demolition applications, offering increased cutting capacity and exceptional on-site performance.
| Characteristics | F200C | F2500C |
|---|---|---|
| Blade Opening (mm) | 205 | 250 |
| Maz. Cutting Force (t) | 85.8 | 85.8 |
| Max. Inlet Pressure (bar) | 200 | 200 |
| Working Pressure (bar) | 200 | 200 |
| Max. Oil Flow (l/min) | 80 | 80 |
| 158 | 225 | |
| Head Rotation | 360º | 360º |
| Blade Closing/Opening Time | 1.7 / 1.3 s (Q = 80 l/min) | 1.7 / 1.3 s (Q = 80 l/min) |
| Weight (kg) | 178 | 182 |
| Dimensions (Closed) (mm) L x W x H | 1098 × 420 × 320 | 1153 × 420 × 320 |
| Dimensions (Open) (mm) L x W x H | 1059 × 344 × 320 | 1118 × 394 × 320 |
| Excavator Weight (min.-max.) (kg) | 1500 / 3000 | 1500 / 3000 |
The main features of these crushing grapples are:
